Antari DFXSpot 510IP; 6 x 365nm, IP Rated UV Spot
Antari DFX-IPS510 DFXSpot 510IP; 6 x 365nm, IP Rated UV Spot High Efficiency UV LED Fixtures
The Antari DFX-IPS510 DarkFX Spot 510 IP is a professionally designed outdoor-rated professional high-output UV LED spot, well suited for UV reactive material, amusement park displays, art, and signage that comes with bright and vivid colors. The 6 x 1.9W high-power UV LEDs are made for offering a peak wavelength of 365nm and a radiant flux output of 4500mW at full intensity (and minimal visible light).
The fixture is made for offering a 15° beam angle and is flicker-free for TV and film production. Special optics are made capable of preventing a wear degradation from high UV exposure. The aluminum extruded enclosure comes featuring a built-in adjustable yoke intended for versatile mounting options. A 22 AWG power/data bare-wire-end pigtail cable is attached on the back and is connecting to the Antari DarkFX Drive 4 fixture driver (sold separately), which is required for power and DMX control.
Note: Requires connection to separately sold DarkFX Drive 4 for power and DMX control
- IP65 outdoor rated
- High-efficiency UV LEDs
- 15° narrow beam angle
- 365nm peak wavelength
- Minimum visible light output
- Special optics to prevent wear degradation from high UV exposure
- 4500mW high-output at full intensity
- Flicker-free operation for TV and Film
Specifications:
| Light Source | 6 x 1.9 W High Power UV LEDs 20,000 Hour Average LED Life |
| Photometrics | Optics: 15° Peak Wavelength: 365nm Radiant Flux Output: 4500 mW |
| Control and Connectors | DarkFX Drive 4 Power/DMX Fixture Driver (Sold Separately) Cable Connection: 22 AWG Bare-Wire Power/Data Combo Cable |
| Power Requirements | Power Input: 20 to 24 VDC Power Consumption: 12 W Max |
| Approvals | CE |
| Ratings | IP65 |
| Dimensions (L x W x H) | 4.3 x 1.8 x 5.3" / 11 x 47 x 13 cm |
| Weight | 1.6 lb / 0.7 kg |
