Antari DarkFX Strip 1020; 12 x 365nm, UV Strip - Requires PD4 MkII
The Elation Professional DarkFX Strip 1020 is a professional high-output UV LED bar, well suited for UV reactive material, art, amusement park displays, and signage with bright and vivid colors. The 12 x 1.9W high-power UV LEDs offer a peak wavelength of 365nm and a radiant flux output of 9000mW at full intensity). The fixture offers a 40° beam angle and is flicker-free for TV and film production. Special optics prevent wear degradation from high-UV exposure.
The IP20-rated (indoor use only) aluminum-extruded housing features an adjustable mounting bracket and comes with a 22 AWG power/data bare-wire-end pigtail cable attached on the back that connects to the Antari DarkFX Drive 4 fixture driver (sold separately) and is required for power and DMX control.
- High-efficiency UV LED bar
- 40° beam angle
- 365nm peak wavelength with minimum visible light
- 9000+mW high-output at full intensity
- Special optics to prevent wear degradation from high UV exposure
- Flicker-free operation for TV and film
Specifications
(6) 1.9W High Power UV LEDs
20,000 Hour Average LED Life*
*LED Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA
Optics: 25 Degrees
Peak Wavelength: 365nm
Radiant Flux Output: 4500 mW
CONTROL/CONNECTIONS
DarkFX Drive 4 Power/DMX Fixture Driver (sold separately)
Cable Connection: 22 AWG Bare Wire Power/Data Combo Cable
SIZE / WEIGHT
Dimensions (no mounting brackets)
Length: 23.4” (593.2mm)
Width: 1.78” (45mm)
Vertical Height: 1.15” (29.15mm)
Dimensions (including mounting brackets)
Length: 23.4” (593.2mm)
Width: 2.91” (74mm)
Vertical Height: 2.85” (72.35mm)
Dry Weight: 2.4 lbs. (1.08 kg)
ELECTRICAL / THERMAL
DC 20-24V
12W Max Power Consumption
APPROVALS / RATINGS
CE | IP20 Indoor Use Only
